ACCESSING DIAGNOSTIC INFO ON THE ILC 2050 BI (Without Using Workbench)

Quickly access diagnostic information from the ILC2050 BI controller.

Training Module – With Timeline References

Applies To:
Phoenix Contact ILC 2050 BI
Niagara 4.x (all firmware variants supporting IL runtime)

Purpose:
This guide shows how to access local diagnostic information directly from the ILC2050 BI using only a USB‑Mini cable and a web browser — no Workbench required.

Use this document in split‑screen mode with the official Phoenix Contact video for accurate, timestamp‑aligned steps.

Video Tutorial: Diagnostics of Phoenix Contact Niagara Controller

1. Introduction (00:00–00:17)

The presenter explains:

• The ILC2050 BI is Phoenix Contact’s Niagara‑based controller.

• The video demonstrates how to access controller diagnostics without Workbench.

• This is especially helpful for quick checks, such as verifying I/O (IL runtime).

2. Required Hardware (00:17–00:31)

You will need:

✔ USB Type‑A to USB Mini‑B Cable

• Connect the USB Mini‑B end to the USB port on the controller.

• When connected, the device exposes a virtual COM/diagnostic interface that hosts a local webpage.

3. Open Diagnostic Web Page (00:31–00:50)

After connecting the USB cable:

1. A virtual driver is automatically created by the controller.

2. Open a web browser (Chrome is shown in the video).

3. Enter the following address in the URL bar:

http://172.16.0.10:8080

This loads the built‑in diagnostic interface.

4. Log Into the Controller (00:50–00:57)

You will be prompted to log in.

• Use your platform credentials.

• After login, diagnostic information is displayed immediately.

5. Platform and Runtime Information (00:57–01:06)

From this screen you can view:

✔ Host ID

Required for licensing and asset management.

✔ Niagara Runtime Status

Shows how long the Niagara controller has been running.

6. Network Information (01:01–01:14)

The ILC2050 BI includes two Ethernet interfaces.

The diagnostic page displays:

• IP address of Port 1

• IP address of Port 2

• Current network configuration state

Each interface can be configured independently.

7. Time & Date Configuration (01:14–01:23)

You can view and adjust:

• System date & time

• Time source

  • NTP (Network Time Protocol), or

  • Manual configuration

8. Switch Configuration (01:23–01:44)

The controller includes a flexible internal switch supporting various port allocations.

You can configure:

• 1 Primary + 3 Secondary Ethernet ports

• 2 + 2 port split

• 3 + 1 port split

• All 4 ports mapped to the primary network

The controller also supports:

✔ Rapid Spanning Tree Protocol (RSTP)

For network redundancy and loop protection.

9. IL Runtime and I/O Diagnostics (01:52–02:24)

This is typically the most valuable part for field engineers.

You can view and test:

Digital Outputs

• Turn ON

• Turn OFF

• Return to AUTO mode

Digital Inputs

• Displays real‑time state

• Update by refreshing the page

• Useful for confirming sensor wiring

RTD Inputs

• Shows live temperature readings

Analog Inputs / Analog Outputs

• Real‑time values

• Status feedback

These tools allow fast commissioning checks without loading Workbench.

10. Live Example (02:20–02:26)

In the video, a digital input is energised by a sensor.
Refreshing the page immediately shows the state change.

This demonstrates how the diagnostic webpage is ideal for:

• Field wiring verification

• IL logic testing

• Quick functional checks

11. Summary (02:28–02:45)

The video closes by encouraging users to:

• View other Phoenix Contact technical videos

• Visit the Niagara/ILC2050 BI support site:
  http://www.phoenixcontact.com/Niagara
