Making a local USB/Serial connection
If a JACE 8000 becomes unreachable over the network then the first point of call is to connect to the device over a local serial connection to see what the status is, and perform any rectifying configuration changes if possible.
Requirements
-
Micro USB cable
-
PuTTY application
How to make a serial connection to the JACE 8000
Connect the USB cable between the controller’s Debug port and the USB port you are using on your PC.
On your PC, start your terminal emulation software. For example to start PuTTY from the Windows
In the tree in the PuTTY Configuration dialog, expand Connection and click Serial.
Set the “Serial line to connect to” for your PC’s (USB) COM port to use. For example, COM7. You can locate the COM port being used within Device Manager on windows.
How to get to Device Manger on windows.
-
Press Windows key + R to open the Run command dialog box.
-
Type devmgmt.msc and press Enter to open the Device Manager.
This will open up a new window, scroll down and drop down the menu Ports (COM & LPT) to reveal COM ports in use. For example bellow port COM7
In the tree in the PuTTY Configuration dialog, click Session and then click/select the “Connection type” as Serial
Set the “Configure the serial line” fields as follows: • Speed (baud): 115200 • Data bits: 8 • Stop bits: 1 • Parity: None • Flow control: None.
Once all has been configured click on Open.
At the login prompt, enter a platform user name, and at the password prompt, the platform password.
When finished making platform changes from the system shell, either reboot if required, or logout and disconnect the USB cable.
Default Credentials
Out of the box, a JACE 8000 comes configured as follows for reference.
Default IP address: 192.168.1.140
User: tridium
Password: niagara
